SKU: 1996874
206,11EUR
Price without VAT
Stock
ManufacturerABB
Catalog number2CCG001233R0001
EAN code7612271517021
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Built-in depth82.5mm
Release characteristicC
Number of poles (total)3
Number of protected poles3
Rated current100A
Rated voltage400V
Rated insulation voltage Ui690V
Rated impulse withstand voltage Uimp6kV
Voltage typeOther
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V15kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V50kA
Frequency50 - 60Hz
Power loss24W
Current limiting class3
Flush-mounted installation✗ No
Concurrently switching neutral conductor✗ No
Over voltage category3
Pollution degree3
Additional equipment possible✓ Yes
Width in number of modular spacings4.5
Degree of protection (IP)IP20
Ambient temperature during operating-25 - 60°C
Connectable conductor cross section multi-wired1 - 50mm²
Connectable conductor cross section solid-core1 - 70mm²
