SKU: 1543303
219,53EUR
Price without VAT
Stock
ManufacturerABB
Catalog number1SVR427035R0000
Product typeCP-E 24/10.0
EAN code4016779669696
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Voltage type of supply voltageAC/DC
1st secondary output voltage24 - 24V
2nd secondary output voltage0 - 0V
3rd secondary output voltage0 - 0V
Max. output current 110A
Max. output current 20A
Max. output current 30A
Secondary voltage adjustable✓ Yes
Nominal value output voltage 124V
Nominal value output voltage 20V
Nominal value output voltage 30V
Nominal value output current 110A
Nominal value output current 20A
Nominal value output current 30A
Short-circuit-proof✓ Yes
Rated supply voltage at AC 50 Hz90 - 132V
Rated supply voltage at AC 60 Hz90 - 132V
Rated supply voltage at DC210 - 375V
Output voltage stabilized✓ Yes
Power consumption270VA
Power output240W
Stabilized✓ Yes
Type of electric connectionScrew connection
Rail mounting possible✓ Yes
Wall mounting possible✗ No
Modular version✗ No
Built-in width83mm
Built-in height123.6mm
Direct mounting possible✗ No
Width83mm
Height123.6mm
Depth123.6mm
Suitable for safety functions✗ No
SIL according to IEC 61508None
Performance level according to EN ISO 13849-1None
Degree of protection (IP)IP20
Degree of protection (NEMA)1
