SKU: 1543185
16,61EUR
Price without VAT
Stock
ManufacturerABB
Catalog number1SVR405622R0100
Product typeCR-U024AC3L
EAN code4013614374272
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Type of electric connectionPlug-in connection
With detachable clamps✗ No
Complete with socket✗ No
Rated control supply voltage Us at AC 50HZ24 - 24V
With LED indication✓ Yes
Rated control supply voltage Us at AC 60HZ24 - 24V
Drive, polarizationPolarized
Voltage type for actuatingAC
Drive, switching attitudeMono stable
Number of contacts as normally closed contact0
Number of contacts as normally open contact0
Number of contacts as change-over contact3
Type of switch contactSingle contact
With forced-guided contacts✗ No
Degree of protection (IP)IP40
Material contactSilver nickel (AgNi)
Material of contact surfaceOther
Width35mm
Voltage type (operating voltage)AC/DC
Height54.4mm
Depth35mm
Operating voltage at AC 50 Hz250 - 250V
Operating voltage at AC 60 Hz250 - 250V
Nominal current10A
Relay technology category according to IEC 61810-7RT I
