SKU: 2009772
536,24EUR
Price without VAT
Stock
ManufacturerCalpeda
Catalog number70U90100000
EAN code8030485534396
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Material motor housingStainless steel
Material quality motor housingStainless steel 304 (1.4301)
Material pump casingCast iron
Material quality pump casingCast iron GG 20 (GJL-200)
Material impeller/pump wheelCast iron
Material quality impeller/pump wheelCast iron GG 20 (GJL-200)
Max. discharge flow21m³/h
Max. static height8.8m
Cable length10m
Number of phases1
Frequency50 Hz
Nominal current4.5A
Motor power input (P1) per motor0.95kW
Motor power output (P2) per motor0.45kW
Insulation class according to IECF
Rotational speed29001/min
Connection outlet sideInternal thread cylindrical BSPP-G (ISO 228-1)
Nominal diameter connection outlet side1 1/2 inch (40)
Connection standard outlet sideISO 228-1
Max. dimension of fixed parts40mm
With cutting system✗ No
Immersing depth5m
