SKU: 2009756
623,95EUR
Price without VAT
Stock
ManufacturerCalpeda
Catalog number62340051000
EAN code8055263002942
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
ModelHorizontal
Material pump casingStainless steel
Material quality pump casingStainless steel 304 (1.4301)
Material impeller/pump wheelStainless steel
Material quality impeller/pump wheelStainless steel 304 (1.4301)
Max. discharge flow4.8m³/h
Max. static height57m
Max. operating pressure8bar
Number of phases1
Frequency50 Hz
Nominal current5.4A
Motor power output (P2) per motor0.75kW
Insulation class according to IECF
Connection inlet sideInternal thread cylindrical BSPP-G (ISO 228-1)
Nominal diameter connection inlet side1 1/4 inch (32)
Connection standard inlet sideISO 228-1
Connection outlet sideInternal thread cylindrical BSPP-G (ISO 228-1)
Nominal diameter connection outlet side1 inch (25)
Connection standard outlet sideISO 228-1
Degree of protection (IP)IP54
Motor efficiency classIE2
