SKU: 2009771
355,82EUR
Price without VAT
Stock
ManufacturerCalpeda
Catalog number70B51031000
EAN code8055263001440
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Material pump casingCast iron
Material quality pump casingCast iron GG 20 (GJL-200)
Max. discharge flow3.6m³/h
Max. static height50m
Max. suction height9m
Max. operating pressure8bar
Number of phases1
Frequency50 Hz
Nominal current4.5A
Motor power input (P1) per motor0.89kW
Insulation class according to IECF
Rotational speed28001/min
Connection inlet sideInternal thread cylindrical BSPP-G (ISO 228-1)
Nominal diameter connection inlet side1 inch (25)
Connection standard inlet sideISO 228-1
Connection outlet sideInternal thread cylindrical BSPP-G (ISO 228-1)
Nominal diameter connection outlet side1 inch (25)
Connection standard outlet sideISO 228-1
Type of driveElectrical
Degree of protection (IP)IP54
With pressure tank✗ No
Motor efficiency classIE2
