SKU: 1015941
57,54EUR
Price without VAT
Stock
ManufacturerEaton
Catalog number286514
Product typePF6-63/4/03
EAN code4015082865146
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Number of poles4
Rated voltage400V
Rated current63A
Rated fault current0.3A
Rated insulation voltage Ui440V
Rated impulse withstand voltage Uimp4kV
Mounting methodDIN rail
Leakage current typeAC
Selective protection✗ No
Short-time delayed tripping✗ No
Surge current capacity0.25kA
Short-circuit breaking capacity (Icw)6kA
With interlocking device✓ Yes
Voltage typeAC
Additional equipment possible✓ Yes
Frequency50 Hz
Degree of protection (IP)IP20
Built-in depth69.5mm
Width in number of modular spacings4
Ambient temperature during operating-25 - 60°C
Pollution degree2
Connectable conductor cross section multi-wired1.5 - 16mm²
Connectable conductor cross section solid-core1.5 - 35mm²
Explosion-proof✗ No
