SKU: 1841118
48,08EUR
Price without VAT
Stock
ManufacturerPhoenix Contact
Catalog number3010217
EAN code4017918091873
Unit of measureKOM
Quantity:
Minimum order quantity (MOQ): 3
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Connectable conductor cross section fine-strand without cable end sleeve70 - 240mm²
Connectable conductor cross section fine-strand with cable end sleeve70 - 70mm²
Connectable conductor cross section solid-core70 - 240mm²
Connectable conductor cross section multi-wired35 - 95mm²
Rated current In415A
Rated voltage1000V
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Number of levels1
Number of clamp positions per level2
Suitable for conductor materialAluminium/copper
Mounting methodDIN rail (top hat rail)/G-rail TH35/G32
Material insulation bodyOther
Operating temperature-60 - 110°C
Inflammability class of insulation material according to with UL94V0
Width36mm
Height100mm
Depth123.6mm
Explosion-tested version 'Ex e'✓ Yes
Closing plate required✗ No
ColourGrey
Internally connected stages✓ Yes
