SKU: 1844889
3,48EUR
Price without VAT
Stock
ManufacturerPhoenix Contact
Catalog number3214259
EAN code4046356575409
Unit of measureKOM
Quantity:
Minimum order quantity (MOQ): 50
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Connectable conductor cross section fine-strand without cable end sleeve0.14 - 4mm²
Connectable conductor cross section fine-strand with cable end sleeve0.14 - 0.14mm²
Connectable conductor cross section solid-core0.14 - 4mm²
Rated current In19A
Rated voltage500V
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Number of levels3
Number of clamp positions per level2
Suitable for conductor materialAluminium/copper
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyOther
Inflammability class of insulation material according to with UL94V0
Width5.2mm
Height90mm
Depth77.5mm
Closing plate required✓ Yes
ColourGrey
Internally connected stages✗ No
