SKU: 1571836
1,88EUR
Price without VAT
Stock
ManufacturerTyco Electronics
Catalog number1SNK508020R0000
EAN code3472595080205
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 10mm²
Connectable conductor cross section solid-core0.5 - 10mm²
Rated current In57A
Rated voltage1000V
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Connection positionSideways
Number of levels1
Number of clamp positions per level2
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-40 - 110°C
Inflammability class of insulation material according to with UL94V0
Width8mm
Width/grid dimension8mm
Height at lowest possible mounting height48.8mm
Length53mm
Explosion-tested version 'Ex e'✓ Yes
Closing plate required✓ Yes
ColourBlue
