SKU: 1571857
4,70EUR
Price without VAT
Stock
ManufacturerTyco Electronics
Catalog number1SNK510150R0000
EAN code3472595101504
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
PEN function possible✗ No
Connectable conductor cross section fine-strand without cable end sleeve0.5 - 16mm²
Connectable conductor cross section solid-core0.5 - 16mm²
Type of electrical connection 1Screw connection
Type of electrical connection 2Screw connection
Connection positionSideways
Number of levels1
Number of clamp positions per level2
Mounting methodDIN rail (top hat rail) 35 mm
Material insulation bodyThermoplastic
Operating temperature-40 - 110°C
Width10mm
Inflammability class of insulation material according to with UL94V0
Width/grid dimension10mm
Height at lowest possible mounting height48.8mm
Length59.5mm
Closing plate required✓ Yes
ColourGreen/yellow
