SKU: 1636199
241,09EUR
Price without VAT
Stock
ManufacturerEaton
Catalog number170228
Product typeFBSMV-63/4/003-A
EAN code4015081667321
Unit of measureKOM
Quantity:
Free shipping
For orders over 100 EUR
Delivery: 2-4 business days
Estimated time for your location
Secure shopping
SSL protection and secure payment
14-day return guarantee
Easy return at no extra cost
Nominal voltage240 - 415V
Nominal current63A
Rated fault current adjustable✗ No
Rated fault current0.03 - 0.03A
Rated insulation voltage Ui440V
Max. delay time0ms
Delay adjustable✗ No
Rated impulse withstand voltage Uimp4kV
Number of poles4
Leakage current typeA
Surge current capacity0.25kA
Frequency50 Hz
Power loss7.4W
With interlocking device✓ Yes
Anti-nuisance tripping version✗ No
Degree of protection (IP)IP20
Ambient temperature during operating-25 - 40°C
Pollution degree2
Connectable conductor cross section multi-wired0.75 - 35mm²
Connectable conductor cross section solid-core0.75 - 35mm²
